24030-BE-XL-2VSR
-
All Data Sourced from Official Brands
-
Brand Alternative Bearings with Identical Specifications
-
Customized Bearing Solutions Based on Parameters
-
Fast Quotation Response
-
OEM and Flexible Order Quantities Supported
Specifications
Availability: 100 PCS
Brand: HSN/ FAG/ OEM
Bearing Number: 24030-BE-XL-2VSR
Category: Spherical Roller Bearings
1
Weight and Dimensions
Bore (d): 150 mm
Outer (D): 225 mm
Width (B): 75 mm
Weight: 11.1 kg
Data from Schaeffler (medias)
Basic Dynamic Load Rating, Radial Cr: 680 KN
Basic Static Load Rating, Radial (C0r): 1090 KN
Fatigue Load Limit, Radial (Cur): 122000 N
Limiting Speed (nG): 690 r/min
Product Properties
Precision: P0, P6, P5
Hardness: HRC58-62
Ring Material: GCr15, GCr15SiMn, 100CrMnSi6-4, etc.
Cage Material: Brass, Steel
Certificate: ISO9001:2015
1
Downloads & Links
FAG Spherical Roller Bearings Guide
Product Description
The 24030-BE-XL-2VSR FAG spherical roller bearing consists of an inner ring, outer ring, two rows of spherical rollers, cages, and seals on both sides. Its self-aligning design accommodates angular misalignment and shaft deflection while supporting high radial loads and axial loads in both directions. The BE design provides high load carrying capacity, while X-life improves operating performance and service life. In addition, the 2VSR sealing system on both sides helps retain lubricant and protect the bearing interior from contaminants, supporting reliable operation in harsh environments.
The 24030-BE-XL-2VSR bearing is suitable for mining and cement, steel and metallurgy, material handling, construction machinery, industrial transmissions, and heavy industrial equipment. Its high load capacity and self-aligning capability support heavy loads and alignment deviations. Meanwhile, the sealed design helps reduce lubricant loss and contamination, making it suitable for applications requiring effective sealing protection and reduced maintenance.
