627-2RS
-
All Data Sourced from Official Brands
-
Brand Alternative Bearings with Identical Specifications
-
Customized Bearing Solutions Based on Parameters
-
Fast Quotation Response
-
OEM and Flexible Order Quantities Supported
Specifications
Availability: 100 PCS
Brand: HSN/ TIMKEN/ OEM
Bearing Number: 627-2RS
Category: Deep Groove Ball Bearings
1
Weight and Dimensions
Bore (d): 7 mm
Outer (D): 22 mm
Width (B): 7 mm
Weight: 0.0120 kg
Data from Timken (medias)
Dynamic Radial Load Rating – 1M Revs (C1): 3300 N
Static Radial Load Rating (C0): 1400 N
Limiting Speed – Oil: 33000 rpm
Limiting Speed – Grease: 39000 rpm
Product Properties
Precision: P0, P6, P5
Hardness: HRC58-62
Ring Material: GCr15, GCr15SiMn, 100CrMnSi6-4, etc.
Cage Material: Brass, Steel
Certificate: ISO9001:2015
1
Downloads & Links
Timken Deep Groove Ball Bearings
Product Description
The 627-2RS Timken miniature deep groove ball bearing consists of an inner ring, an outer ring, balls, a cage, and two contact seals. Its compact design supports radial and bidirectional axial loads, while the contact seals provide effective protection against dust, moisture, and contaminants and help retain lubricant for reliable operation.
The 627-2RS bearing is widely used in small machinery, compact drives, miniature pumps, automation equipment, and precision mechanical systems. It is particularly suitable for space-limited applications requiring effective sealing, lubricant retention, and reliable operation in contaminated environments.
