NP2268
-
All Data Sourced from Official Brands
-
Brand Alternative Bearings with Identical Specifications
-
Customized Bearing Solutions Based on Parameters
-
Fast Quotation Response
-
OEM and Flexible Order Quantities Supported
Specifications
Availability: 100 PCS
Brand: HSN/ ARB/ OEM
Bearing Number: NP2268
Category: Cylindrical Roller Bearings
1
Weight and Dimensions
Bore (d): 340 mm 13.3858 in
Outer Diameter (D): 620 mm 24.4094 in
Width (W): 165 mm 6.4961 in
Weight: 220 kg 485 lbs
Data from ARB (medias)
Dynamic Capacity (C) : 2640 KN 593500 lbs
Static Capacity (Co) : 4500 KN 1012000 lbs
Product Properties
Precision: P0, P6, P5
Hardness: HRC58-62
Ring Material: GCr15, GCr15SiMn, 100CrMnSi6-4, etc.
Cage Material: Brass, Steel
Certificate: ISO9001:2015
1
Downloads & Links
ARB Cylindrical Roller Bearings Guide
Product Description
The American Roller Bearing NP2268 cylindrical roller bearing consists of a double-ribbed inner ring, an outer ring with one integral rib and one loose flange ring, cylindrical rollers, and a cage. Its line-contact roller design provides high radial load capacity and rigidity, while the rib arrangement provides axial location and supports axial loads in both directions. The separable construction facilitates mounting and maintenance while providing stable performance under demanding loads. It is suitable for electric motors, industrial gearboxes, conveyors, mining equipment, crushers, and other heavy-duty machinery requiring reliable radial support and bidirectional axial location.
