1219-M
-
All Data Sourced from Official Brands
-
Brand Alternative Bearings with Identical Specifications
-
Customized Bearing Solutions Based on Parameters
-
Fast Quotation Response
-
OEM and Flexible Order Quantities Supported
Specifications
Availability: 100 PCS
Brand: HSN/ FAG/ OEM
Bearing Number: 1219-M
Category: Self-aligning Ball Bearings
1
Weight and Dimensions
Bore (d): 95 mm
Outer (D): 170 mm
Width (B): 32 mm
Weight: 3.32 kg
Data from Schaeffler (medias)
Basic Dynamic Load Rating, Radial Cr: 64000 N
Basic Static Load Rating, Radial (C0r): 27000 N
Fatigue Load Limit, Radial (Cur): 1450 N
Limiting Speed (nG): 6300 rpm
Reference Speed (nϑr): 4600 rpm
Product Properties
Precision: P0, P6, P5
Hardness: HRC58-62
Ring Material: GCr15, GCr15SiMn, 100CrMnSi6-4, etc.
Cage Material: Brass, Steel
Certificate: ISO9001:2015
1
Downloads & Links
FAG Self-aligning Ball Bearings
Product Description
The 1219-M FAG self-aligning ball bearing consists of an inner ring with two raceway grooves, an outer ring with a spherical raceway, two rows of balls, and a solid brass cage. The self-aligning design compensates for shaft deflection, mounting misalignment, and housing deformation while supporting radial and axial loads in both directions. The robust M brass cage provides reliable ball guidance and stable operation under demanding conditions.
The 1219-M bearing is widely used in industrial fans, drying systems, material handling equipment, process machinery, and industrial transmission systems. It is particularly suitable for applications involving shaft deflection or mounting misalignment while requiring robust cage performance, elevated operating temperatures, and reliable continuous operation.
