T138XS
-
All Data Sourced from Official Brands
-
Brand Alternative Bearings with Identical Specifications
-
Customized Bearing Solutions Based on Parameters
-
Fast Quotation Response
-
OEM and Flexible Order Quantities Supported
Description
Specifications
Availability: 100 PCS
Brand: HSN/ Timken/ OEM
Bearing Number: T138XS
Category: Tapered Roller Thrust Bearings
1
Weight and Dimensions
Bore (d): 35.179 mm 1.385 in
Outer Diameter (D): 66.675 mm 2.625 in
Width (T): 19.446 mm 0.7656 in
Max fillet: 0.8 mm 0.03 in
Weight: 0.3 kg 0.7 lbs
Data from Timken (medias)
Steering Pivot Rating : 42200 N 9450 lbf
Product Properties
Precision: P0, P6, P5
Hardness: HRC58-62
Ring Material: GCr15, GCr15SiMn, 100CrMnSi6-4, etc.
Cage Material: Brass, Steel
Certificate: ISO9001:2015
1
Downloads & Links
Timken Tapered Roller Thrust Bearings
Product Description
The TIMKEN T138XS tapered roller thrust bearing consists of two tapered thrust races, a full complement of tapered rollers without a cage, and a stamped steel retaining ring pressed onto the outer diameter. Its full complement design provides reliable axial load capacity, while the retaining ring keeps the bearing components together for convenient handling and installation. Featuring two bore diameters of 35.179 mm and 35.387 mm, the bearing is designed for oscillating applications requiring stable axial support in the United States industrial market.
