T194W
-
All Data Sourced from Official Brands
-
Brand Alternative Bearings with Identical Specifications
-
Customized Bearing Solutions Based on Parameters
-
Fast Quotation Response
-
OEM and Flexible Order Quantities Supported
Description
Specifications
Availability: 100 PCS
Brand: HSN/ Timken/ OEM
Bearing Number: T194W
Category: Tapered Roller Thrust Bearings
1
Weight and Dimensions
Bore (d): 49.454 mm 1.947 in
Outer Diameter (D): 93.269 mm 3.672 in
Width (T): 26.975 mm 1.062 in
Max fillet: 0.8 mm 0.03 in
Weight: 0.8 kg 1.8 lbs
Data from Timken (medias)
Steering Pivot Rating : 86000 N 19400 lbf
Product Properties
Precision: P0, P6, P5
Hardness: HRC58-62
Ring Material: GCr15, GCr15SiMn, 100CrMnSi6-4, etc.
Cage Material: Brass, Steel
Certificate: ISO9001:2015
1
Downloads & Links
Timken Tapered Roller Thrust Bearings
Product Description
The TIMKEN T194W tapered roller thrust bearing consists of two tapered thrust races, a full complement of tapered rollers without a cage, and a stamped steel retaining ring wrapped around one thrust race. The retaining ring incorporates oil holes to facilitate lubrication, while the full complement roller design provides reliable axial load capacity and stable support under thrust loads. This construction is specifically designed for oscillating applications requiring dependable axial support in the United States industrial market.
