K41125-41286
-
All Data Sourced from Official Brands
-
Brand Alternative Bearings with Identical Specifications
-
Customized Bearing Solutions Based on Parameters
-
Fast Quotation Response
-
OEM and Flexible Order Quantities Supported
Specifications
Availability: 100 PCS
Brand: HSN/ FAG/ OEM
Bearing Number: K41125-41286
Category: Tapered Roller Bearings
1
Weight and Dimensions
Bore (d): 28.575 mm
Outer (D): 72.626 mm
Width, Inner Ring (B): 24.257 mm
Width, Outer Ring (C): 17.462 mm
Width, Total (T): 24.608 mm
Weight: 0.492 kg
Data from Schaeffler (medias)
Basic Dynamic Load Rating, Radial Cr: 56000 N
Basic Static Load Rating, Radial (C0r): 53000 N
Fatigue Load Limit, Radial (Cur): 6000 N
Limiting Speed (nG): 10900 r/min
Product Properties
Precision: P0, P6, P5
Hardness: HRC58-62
Ring Material: GCr15, GCr15SiMn, 100CrMnSi6-4, etc.
Cage Material: Brass, Steel
Certificate: ISO9001:2015
1
Downloads & Links
FAG Tapered Roller Bearings Guide
Product Description
The K41125-41286 FAG single row tapered roller bearing consists of an inner ring, outer ring, tapered rollers, and a cage. Its tapered roller and raceway geometry provides high radial load capacity, axial load capability in one direction, and high rigidity. In addition, the design distributes combined loads effectively and supports stable operation under changing load conditions.
The K41125-41286 bearing is suitable for the automotive industry, agricultural machinery, industrial transmissions, construction machinery, and material handling. Its combined radial and axial load capacity provides dependable support under variable loads. Therefore, it is well suited to applications requiring stable performance and durable operation.
