T7FC075-XL
-
All Data Sourced from Official Brands
-
Brand Alternative Bearings with Identical Specifications
-
Customized Bearing Solutions Based on Parameters
-
Fast Quotation Response
-
OEM and Flexible Order Quantities Supported
Specifications
Availability: 100 PCS
Brand: HSN/ FAG/ OEM
Bearing Number: T7FC075-XL
Category: Tapered Roller Bearings
1
Weight and Dimensions
Bore (d): 75 mm
Outer (D): 150 mm
Width, Inner Ring (B): 38 mm
Width, Outer Ring (C): 29 mm
Width, Total (T): 42 mm
Weight: 3.22 kg
Data from Schaeffler (medias)
Basic Dynamic Load Rating, Radial Cr: 238000 N
Basic Static Load Rating, Radial (C0r): 275000 N
Fatigue Load Limit, Radial (Cur): 42500 N
Limiting Speed (nG): 4950 rpm
Reference Speed (nϑr): 3950 rpm
Product Properties
Precision: P0, P6, P5
Hardness: HRC58-62
Ring Material: GCr15, GCr15SiMn, 100CrMnSi6-4, etc.
Cage Material: Brass, Steel
Certificate: ISO9001:2015
1
Downloads & Links
FAG Tapered Roller Bearings Guide
Product Description
The T7FC075-XL FAG single row tapered roller bearing consists of an inner ring, outer ring, tapered rollers, and a cage. Its tapered roller and raceway geometry provides high radial load capacity, axial load capability in one direction, and high rigidity. The design also promotes effective load distribution and stable operation under combined radial and axial loads.
The T7FC075-XL bearing is suitable for agricultural machinery, industrial transmissions, material handling, power generation, and construction machinery. Its combined load capacity provides stable support under radial and axial forces, while improved operating performance supports efficient and continuous operation across demanding industrial applications.
