23176-BEA-XL-2RSR-MB1
-
All Data Sourced from Official Brands
-
Brand Alternative Bearings with Identical Specifications
-
Customized Bearing Solutions Based on Parameters
-
Fast Quotation Response
-
OEM and Flexible Order Quantities Supported
Specifications
Availability: 100 PCS
Brand: HSN/ FAG/ OEM
Bearing Number: 23176-BEA-XL-2RSR-MB1
Category: Spherical Roller Bearings
1
Weight and Dimensions
Bore (d): 380 mm
Outer (D): 620 mm
Width (B): 194 mm
Weight: 234 kg
Data from Schaeffler (medias)
Basic Dynamic Load Rating, Radial Cr: 4750 KN
Basic Static Load Rating, Radial (C0r): 7600 KN
Fatigue Load Limit, Radial (Cur): 530000 N
Limiting Speed (nG): 248 r/min
Product Properties
Precision: P0, P6, P5
Hardness: HRC58-62
Ring Material: GCr15, GCr15SiMn, 100CrMnSi6-4, etc.
Cage Material: Brass, Steel
Certificate: ISO9001:2015
1
Downloads & Links
FAG Spherical Roller Bearings Guide
Product Description
The 23176-BEA-XL-2RSR-MB1 FAG spherical roller bearing consists of an inner ring, outer ring, two rows of spherical rollers, a solid brass cage, and seals on both sides. Its self-aligning design accommodates angular misalignment and shaft deflection while supporting high radial loads and axial loads in both directions. The BEA design provides high load carrying capacity, while X-life improves operating performance and service life. In addition, the MB1 single-piece solid brass cage provides robust roller guidance, while the 2RSR seals help retain lubricant and protect the bearing interior from contaminants.
The 23176-BEA-XL-2RSR-MB1 bearing is suitable for mining and cement, steel and metallurgy, paper machinery, material handling, industrial transmissions, and heavy industrial equipment. Its high load capacity, self-aligning capability, and robust brass cage support heavy loads and alignment deviations. Meanwhile, the sealed design helps reduce lubricant loss and contamination, making it suitable for applications requiring effective sealing protection and reduced maintenance.
